D1696
A
D1695
B
0209 3
7
1
2
Notice
Date Page
05102004
INSTALLATION
MANUAL
7. Installation
• Unscrew the six A screws maintaining the
bridles of the ap (g. 1).
• Remove the three bridles (g. 1).
• Remove eventually the screws and the
linen collector to have a better access.
• Open the ap into its position (g. 2).
• Screw the two B screws inside the lateral
boxes to maintain the ap by each side (g.
2).
Proceed in reverse order in case of transport
of the machine.
Setting of ap
CAUTION
Before putting the machine into service, it is compulsory to set the
ap of the linen collector.
Linen collector
