Q&CI - Technical Support 9 599 844 - 908 Rev. 01
3.6 User interface “LUX”
NIU5 board
with & without
MACS
MACS
Selector
temperature for
single oven
Selector for
double oven
Memory
programming
Programming
factory
Processor
USB programming NIU5
DAAS
Optional
Optional
Selector
temperature
for double
oven
External HMI
