Heatingunit,electric
Connectthenewelement.Reconnectthewiresasbefore,usetheelectricschematicsupplied
withthemachine.
Mounttheelementunitbackinthemachineandfastenthethreescrewsunderthemachine.
Carefullyputthedrumpackagebackinthemachine.
Fastenthesupportrollersatthefrontofthemachine.
ConnecttheRMCandthe“FREE”connectionifdisconnected.
Connectthewiresandmountthecoverpaneltotheelectricalconnections.
Fastenthefourscrewsatthepanelaroundtheheatingelementandtherestofthescrewson
thepanel.
Fastenthebelt.Rotatethedrumtomakesurethatthebeltisinposition.
Mounttheairchannelpanel.
Connecttheoverheatingthermostatandtheheatingsensor.
Mountthetoppanel,thecoverpanelattheairoutletandthecasingovertherearpanel.
T5130C
Disconnectthepowertothemachine.
Demountthecasingovertherearpanel.
Disconnecttheoverheatingthermostatandtheheatingsensorandpushtheconnectionsintothe
hole.
g.7519C
