Electrolux T5130 - Technical Data; Dimensional Drawings

Technicaldata
7
2Technicaldata
2.1Drawing
A
C
2
B
E
D
3
G
4
F
E
D
3
I
5
H
1
g.7250A
1
Operatingpanel
2Dooropening,⌀370mm
3Electricalconnection
4Exhaustconnection
5
Condenseconnection
AB
C
DEF
G
H
mm
5957358508080100200235
IJK
mm
11530070
