Electrolux T5130 - Belt Check and Replacement

92
Maintenance
Remountthemotor.
Tightenthefourscrewsunderthemachine.
Carefullyputthenewdrumpackagebackinthemachine.
Fastenthesupportrollersatthefrontofthemachine.
ConnecttheRMCandthe“FREE”connectionifdisconnected.
Connectthewiresandmountthecoverpaneltotheelectricalconnections.
Fastenthefourscrewsatthepanelaroundtheheatingelementandtherestofthescrewson
thepanel.
Fastenthebelt.Rotatethedrumtomakesurethatthebeltisinposition.
Mounttheairchannelpanel.Oncondensemachines:Retthehosebeforemountingtheair
channelpanel.
Connecttheoverheatingthermostatandtheheatingsensor.
Mountthetoppanel,thecoverpanelattheairoutletandthecasingovertherearpanel.
13.5Checkthebelt
Checkthatbothofthebeltsarenotwornout.Replaceifnecessary.
T5130
T5130C
g.7522A
