10
Setup
3.3
Mechanical
installation
Level
the
machine
with
the
feet
of
the
machine.
The
maximum
height
adjustment
of
the
feet
is
14
mm.
g.W00177
②
3.4
Stacking
frame
The
machine
can
be
installed
on
top
of
a
another
130
litre
tumble
dryer
or
a
53
litre
washer
extractor
.
Make
sure
that
the
machine
that
shall
be
at
the
bottom
is
in
level.
Also
make
sure
the
top
panel
is
clean
before
starting
the
installation.
Place
the
stacking
frame
on
top
of
the
machine
that
shall
be
at
the
bottom
and
fasten
the
bracket
(A)
on
the
stacking
frame.
00
00
00
0
00
A
g.W00188
③
9
