Electrolux T5130C - Heating Sensor (NTC-Sensor)

20
Sensorsandoverheatingthermostats
5.2.2Heatingsensor(NTC-sensor)
DescriptionT5130C
Theheatingsensorisplacednexttotheoutletoverheatingthermostatbehindthedoorswitch.
TheheatingsensormeasuresthetemperatureintheoutletairandthesignalisreturnedtothePCB.
ThePCBturnstheheatingunitoffwhentheoutletairthermistorindicatesthattherequired
temperaturehasbeenreached.
Replacementofheatingsensor(NTC-sensor)T5130C
Disconnectthepowertothemachine.
Openthedooranddemountthedoorswitch.Disconnecttheheatingsensorandremoveit.
Connectthenewheatingsensor.
g.7597
⑬
Remountthedoorswitch.
