30
Motor
7.2Replacementofthebeltaroundthemotorpulley
Disconnectthepowertothemachine.
Demountthecasingovertherearpanelandthecoverpanelattheairoutlet.
Demountthetoppanel.
Disconnecttheoverheatingthermostatandtheheatingsensorandpushtheconnectionsintothe
hole.
g.7519A
29
Demounttheairchannelpanel.Oncondensemachines:Pulloutthehosetothedrainfromits
upperconnection.
Loosenthebeltaroundthedrum.
g.7522A
30
