Motor
31
Unscrewthefourscrewsatthepanelaroundtheheatingelement.
Demountthecoverpaneltotheelectricalconnectionsanddisconnectallwires.
g.7527
31
Unscrewtherestofthescrewsonthepanel.
DisconnecttheRMCandcutthecableties.Ifthereisa“FREE”connection,disconnectit.
Atthefrontofthemachine:Openthedoorandremovethetwoplugs.Loosenthescrewscounter
clockwiseuntiltheystoptoreleasethesupportrollers.
Removethecompletedrumpackagewiththerearpanelbyliftinginthedrumbelt.
g.7531
