Drum
49
Unscrewthefourscrewsatthepanelaroundtheheatingelement.
Demountthecoverpaneltotheelectricalconnectionsanddisconnectallwires.
g.7527
57
Unscrewtherestofthescrewsonthepanel.
DisconnecttheRMCandcutthecableties.Ifthereisa“FREE”connection,disconnectit.
Atthefrontofthemachine:Openthedoorandremovethetwoplugs.Loosenthescrewscounter
clockwiseuntiltheystoptoreleasethesupportrollers.
Removethecompletedrumpackagewiththerearpanelbyliftinginthedrumbelt.
Carefullyputthedrumpackageontheoorwithttherearpanelfacingupwards.
g.7531
58
