Electrolux T5130C - Page 52

52
Drum
Unscrewthefourscrewsatthepanelaroundtheheatingelement.
Demountthecoverpaneltotheelectricalconnectionsanddisconnectallwires.
g.7527
62
Unscrewtherestofthescrewsonthepanel.
DisconnecttheRMCandcutthecableties.Ifthereisa“FREE”connection,disconnectit.
Atthefrontofthemachine:Openthedoorandremovethetwoplugs.Loosenthescrewscounter
clockwiseuntiltheystoptoreleasethesupportrollers.
Removethecompletedrumpackagewiththerearpanelbyliftinginthedrumbelt.
g.7531
63
