Electrolux T5130C - Page 77

Troubleshooting
77
12:5OUTLETAIRSENSOR-OPEN
Theerrorcodeisactivatediftheoutletairsensororitswiresisopen.
IftheoutletairtemperatureintheSHOWINPUTSmenushowatemperatureof-10°Ctheoutletair
sensorisopen.
Whentheoutletairsensorisrestoredtheerrorcodeisautomaticallyresetandtheongoingprogram
willcontinue.Alongpressonthecontrolknob/startbuttonwillmakethetimerresetandongoing
programwillbeended.
Theerrorcodecanbetriggedif:
•Thesensor,harnessorconnectorisbroken.
Thesensorshallmeasurearound5KOhminroomtemperature,seetable.(Measuredirectover
thesensor).
IfthemeasureofoutletairisOK,butthereisstillanerrorcode:
•Checktheharness,connectorsandfunctionsbyreadingtheelectricalschematicandbyusing
theSHOWINPUTSmenuwhenthemachineisinservicemode.
Iftheinputfortheoutletairsensorisshortcircuitedthetimerwilldisplaytheinletairtemperature
of100°C.
Outletairsensorresistorvalue
Temperature
26.7KOhm–10°C
6–3.9KOhm20–30°C
330Ohm100°C
12:6OUTLETAIRSENSOR-SHORT-CIRCUITED
Theerrorcodeisactivatediftheoutletairsensororitswiresisshortcircuited.
IftheoutletairtemperatureintheSHOWINPUTSmenushowatemperatureof100°Ctheoutletair
sensorisopen.
Whentheoutletairsensorisrestoredtheerrorcodeisautomaticallyresetandtheongoingprogram
willcontinue.Alongpressonthecontrolknob/startbuttonwillmakethetimerresetandongoing
programwillbeended.
Theerrorcodecanbetriggedif:
•Thesensor,harnessorconnectorisbroken.
Thesensorshallmeasurearound5KOhminroomtemperature,seetable.(Measuredirectover
thesensor).
IfthemeasureofoutletairsensorisOK,butthereisstillanerrorcode:
•Checktheharness,connectorsandfunctionsbyreadingtheelectricalschematicandbyusing
theSHOWINPUTSmenuwhenthemachineisinservicemode.
Iftheinputfortheoutletairsensorisopencircuitedthetimerwilldisplaytheinletairtemperatureof
0°C.
Outletairsensorresistorvalue
Temperature
26.7KOhm–10°C
6–3.9KOhm20–30°C
330Ohm100°C
