10
Connector numbers
In the error analyses in the section "Troubleshooting" later in this manual
connections P1-P23 are mentioned.
The P-numbers are printed on the print board.
The usage of the connections appears from the wiring diagrams supplied
with the dryer.
The positionings of P1-P23 are shown on the following page.
High voltage on the printed circuit board
Do not touch the printed circuit board.
The shaded areas indicate high voltage.
2
See view 1
next page
See view 2
next page
WARNING!
The shaded areas indicate high voltage.
