18
Marineinstallation
4Marineinstallation
4.1Siting
Installthemachineclosetoaoordrainoropendrain.
Themachineshouldbepositionedsothatthereisplentyofroomforworking,bothfortheuser
andservicepersonnel.
Thegureshowsminimumdistancetoawalland/orothermachines.
⑨
1000 mm /
39 3/8 inch
50 mm /
1 15/16 inch
50 mm /
1 15/16 inch
g.W00176E
