Electrolux W5330N - 9 Steam Connection

44
Steamconnection
9Steamconnection
Inletpipesconnectedtothemachinemustbeequippedwithamanualshut-offvalvetofacilitate
installationandservicing.
TheconnectionhosemustbeoftypeISO/1307-1983orequivalent.
Connectionsizeatlter:DN15(BSP1/2").
Demountthetoppanel(A).
Demountthecasing(B.
27
A
B
g.6600
Mountthenippletothesteamvalve.
Mountthesteamvalveonthemachine.
Mountnipple,strainerandelbow.Notethedirectionofthestrainer.
Mountsteamhosetotheelbow.
Checkthattherearenosharpanglesorbendsontheconnectedsteamhose.
28
g.5862A
