Electricalconnection
37
8.3.2Three-phaseconnection
Connecttheearth,neutralandphasewiresasshown.
3AC
T1
T2
T3
L1
N
N
L2
L3
3AC
L1 L2 L3
3NAC
T1
T2
T3
L1
N
N
L2
L3
3NAC
N L1 L2 L3
