Electrolux W5330N - Mechanical Installation

Marineinstallation
19
4.2Mechanicalinstallation
Toensuresteadinessofthemachineitisimportanttofastenthemachinetothefoundation.
Levelthemachinebyusingstainlessorgalvanizedsteelwashersbetweenthemachineandthe
oor.Thewashersmustbeofasizetocoverthesupportsurface.Fitthewashersandself-locking
nutssuppliedwiththemachineandtightenwell.T otightenthenutsitisrecommendedtousea
rachetwrench,especiallyintherightrearcorner.
Itisoftheupmostimportancethatthemachineisplacedinlevel,fromsidetosideaswellasfronttorear.If
themachineisnotproperlylevelled,itmayresultinout-of-balancewithoutarealoutofbalanceinthedrum.
⑩
g.5463A
Afterthemachinehasbeeninuseforawhile,checkandre-tightenthenutsifnecessary.
Floor
Inthistypeofmachine,thedrumisattacheddirectlytotheframe.Asaresultthedeckunderthe
machinemustbestableenoughtoabsorbthedynamicforcesgeneratedduringspincycles.
Thecombinationdeckandfoundationmustbeabletowithstandtheloadsindicatedinthetechnical
datatable.
Somemarineinstallationshaveverythindecks.Specialattentiontobetaken.Reinforcingdeck
plusincreasedsizeoffoundationmaybenecessary.
