Electronics International VA-1A - VA-1 A (Internal Shunt Unit) Wiring Diagram

VV
VV
V
A-1AA-1A
A-1AA-1A
A-1A
(Internal Shunt Unit)(Internal Shunt Unit)
(Internal Shunt Unit)(Internal Shunt Unit)
(Internal Shunt Unit)
Wiring DiagramWiring Diagram
Wiring DiagramWiring Diagram
Wiring Diagram
W0225921
16
Red
Black
Wht/Brn
Wht/Red
Wht/Yel
To Bus via 1 to 2 Amp Fuse.
To Ground.
To 12-Volt Bus (Open for 24-volt
To 24-Volt Bus (grounded for 12-
To External Warning Light (pulls
system). 12-Volt Back Light.
volt system). 24-Volt Back Light.
low when the Discharge or High
Volts Light is on).
#4 Wire or larger.
#4 Wire or larger.
Circular Connector
Wire Harness
VA-1A Back Panel
12/24 Volt Switch (Up for 24-volt system)
(Down for 12-volt system)
