PS 2000 B Triple Series
Overview
For a detailed description of the display and its layout see section «1.9.4. The control panel (HMI)». The HMIs of
the outputs 1 and 2 are identical.
(1)
Power switch
Usedtopowerthedeviceonando󰀨.
(2)
Pushbutton “Settings”
UsedforaccesstothesetupmenuwhiletheDCoutputisswitchedo󰀨.
(3)
Color display
Used for display of set values, menus, actual values and status.
(4)
Rotary knob with push button function
Turn: adjustment of the voltage set value or selection of parameters in the menu
Push: selection of the decimal position (cursor) of the currently assigned value
(5)
USB port
Used to connect the device to a PC or other control hardware to establish communication and remote control
(6)
Rotary knob with push button function
Turn: adjustment of the current set value or adjustment of parameter value in the menu
Push: selection of the decimal position (cursor) of the currently assigned value
(7)
Pushbutton “On/O󰀨”
UsedtoswitchtheDCoutputoonoro󰀨,unlesstheHMIisfullylockedorremotecontrolisactive.Isalso
used to acknowledge, i. e. clear alarms before the DC output on again.
(8)
Connectors of DC output 1
TheredandblacksafetysocketsformapoledDCoutput.Theyallowfortheuseofspecic4mmsafety
plugs with or without retractable shell.
(9)
Connectors of DC output 2
TheredandblacksafetysocketsformapoledDCoutput.Theyallowfortheuseofspecic4mmsafety
plugs with or without retractable shell.
(10)
Connectors of DC output 3
TheredandblacksafetysocketsformapoledDCoutput.Theyallowfortheuseofspecic4mmsafety
plugs with or without retractable shell. Its output voltage can be adjusted with a trimmer (small hole be-
tween the sockets). The LED indicates constant voltage operation, it means it’s lit as long as the maximum
current isn’t reached.
(11)
PE socket
4 mm socket which can be used to ground one of the output poles on the three DC outputs and/or external
hardware.
