PS 2000 B Triple Series
1.8.3 Specic technical data
42 V / 84 V
Model
PS 2342-06 B PS 2342-10 B PS 2384-03 B PS 2384-05 B
AC Input
Voltage range 90...264 V AC 90...264 V AC 90...264 V AC 90...264 V AC
Connection Wall outlet Wall outlet Wall outlet Wall outlet
Frequency 45-65 Hz 45-65 Hz 45-65 Hz 45-65 Hz
Fusing MT 4 A MT 6.3 A MT 4 A MT 6.3 A
Power factor ≈0.99 ≈0.99 ≈0.99 ≈0.99
Output 1 & 2 - Voltage
Adjustment range 0...42 V 0...42 V 0...84 V 0...84 V
Accuracy
(1
(at 23 ± 5°C) < 0.2% U
Max
< 0.2% U
Max
< 0.2% U
Max
< 0.2% U
Max
Load regulation at 0...100% load < 0.15% U
Max
< 0.15% U
Max
< 0.15% U
Max
< 0.15% U
Max
Settling time after load step < 2 ms < 2 ms < 2 ms < 2 ms
Overvoltage protection 0...46.2 V 0...46.2 V 0...92.4 V 0...92.4 V
Display: Accuracy
(3
≤0.2%U
Max
≤0.2%U
Max
≤0.2%U
Max
≤0.2%U
Max
Ripple
(2
< 100 mV
PP
< 4 mV
RMS
< 63 mV
PP
< 5 mV
RMS
< 48 mV
PP
< 4 mV
RMS
< 96 mV
PP
< 24 mV
RMS
Output 1 & 2 - Current
Adjustment range 0...6 A 0...10 A 0...3 A 0...5 A
Accuracy
(1
(at 23 ± 5°C) < 0.3% I
Max
< 0.3% I
Max
< 0.3% I
Max
< 0.3% I
Max
Loadregulationat0...100%ΔU
OUT
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
Overcurrent protection 0...6.6 V 0...11 V 0...3.3 V 0...5.5 V
Display: Accuracy
(3
≤0.2%I
Max
≤0.2%I
Max
≤0.2%I
Max
≤0.2%I
Max
Ripple
(2
< 4 mA
RMS
< 5 mA
RMS
< 2 mA
RMS
< 3 mA
RMS
Output 1 & 2 - Power
Rated power 2x 100 W 2x 160 W 2x 100 W 2x 160 W
Output 3
Adjustment range 3...6 V
Rated power 10 W (max. 12 W)
Lineregulation±10%ΔU
E
< 0.02%
Loadregulationat0...100%ΔU
OUT
< 1.2 %
Ripple < 100 mV
PP
Rated current > 2 A @ 5 V, > 3.3 A @ 3 V
Miscellaneous
Cooling Fanless, natural convection
Ambient temperature 0..50°C
Storage temperature -20...70°C
Humidity < 80%, not condensing
Standards EN 61010-1
Overvoltage category 2
Protection class 1
Dimensions (WxHxD) 282 x 82 x 241 mm
Weight ≈3.3kg ≈3.5kg ≈3.3kg ≈3.5kg
Article number 39200120 39200121 39200125 39200126
(1Relatedtothenominalvalues,theaccuracydenesthemaximumdeviationbetweenanadjustedvaluesandthetrue(actual)value.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz.
(3 The display error adds to the error of the related actual value on the DC output.
