PSB 9000 3U Series
5 kW
Model 400 V / 480 V
PSB 9060-120 PSB 9080-120 PSB 9200-70 PSB 9360-40 PSB 9500-30
Power regulation
Adjustment range 0…5100 W 0…5100 W 0…5100 W 0…5100 W 0…5100 W
Accuracy
(1
(at 23 ± 5 °C / 73±9 °F)
< 1% P
Max
< 1% P
Max
< 1% P
Max
< 1% P
Max
< 1% P
Max
Line regulation at ±10% ΔU
AC
< 0.05% P
Max
< 0.05% P
Max
< 0.05% P
Max
< 0.05% P
Max
< 0.05% P
Max
Load reg. at 10-90% ΔU
DC
* ΔI
DC
< 0.75% P
Max
< 0.75% P
Max
< 0.75% P
Max
< 0.75% P
Max
< 0.75% P
Max
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy
(2
≤ 0.8% P
Max
≤ 0.8% P
Max
≤ 0.8% P
Max
≤ 0.8% P
Max
≤ 0.8% P
Max
E󰀩ciency
(5
≈ 93% ≈ 93% ≈ 95% ≈ 95% ≈ 95,5%
Resistance regulation
Adjustment range 0.02...25 Ω 0.02...25 Ω 0.1...150 Ω 0.3...520 Ω 0.5...1000 Ω
Accuracy
(1
(at 23 ± 5 °C / 73±9 °F)
≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Analog interface
(3
Signals See „3.6.4.4. Analog interface specication“
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±400 V DC ±400 V DC ±725 V DC ±725 V DC ±1500 V DC
Positive DC to PE Max. ±400 V DC ±400 V DC ±1000 V DC ±1000 V DC ±1800 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1, EN 50160:2011-02, EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x GPIB (optional)
Slot (standard version)
Optional: CANopen, Probus, Pronet, RS232, CAN, Ethernet, ModBus TCP, Ether-
CAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side
Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, master-
slave bus, interface module slot (standard version) or GPIB (optional)
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 3U x 670 mm (26.4”)
Total (W x H x D) 483 x 133 x 775 mm (19” x 5.2” x 30.5”)
Weight ≈18 kg (39.7 lb) ≈18 kg (39.7 lb) ≈18 kg (39.7 lb) ≈18 kg (39.7 lb) ≈18 kg (39.7 lb)
Article number
(4
30000319 30000301 30000302 30000303 30000304
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see „3.6.4.4 Analog interface specication“ on page 64
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power
