PSB 9000 3U Series
5 kW / 10 kW
Model 400 V / 480 V
PSB 9750-20 PSB 9060-240 PSB 9080-240 PSB 9200-140 PSB 9360-80
AC supply
Voltage range (L-L), frequency 342...528 V AC, 45 - 66 Hz
Connection 2ph, PE 3ph, PE 3ph, PE 3ph, PE 3ph, PE
Leak current < 3.5 mA < 3.5 mA < 3.5 mA < 3.5 mA < 3.5 mA
Phase current max. 16 A max. 28 A max. 28 A max. 28 A max. 28 A
Power factor
≈ 0.99
E󰀩ciency of energy recovery ≤ 94.5% ≤ 92.5% ≤ 92.5% ≤ 93.5% ≤ 93.5%
DC terminal
Max. voltage U
Max
750 V 60 V 80 V 200 V 360 V
Max. current I
Max
20 A 240 A 240 A 140 A 80 A
Max. power P
Max
5000 W 10000 W 10000 W 10000 W 10000 W
Overvoltage protection range 0...825 V 0...66 V 0...88 V 0...220 V 0...396 V
Overcurrent protection range 0...22 A 0...264 A 0...264 A 0...154 A 0...88 A
Overpower protection range 0…5500 W 0…11000 W 0…11000 W 0…11000 W 0...11000 W
Temperature coe󰀩cient for set
values Δ/K
Voltage / current: 100 ppm
Capacitance (approx.) 180 μF 15980 μF 15980 μF 5040 μF 780 μF
Voltage regulation (general)
Adjustment range 0...765 V 0...61.2 V 0...81.6 V 0...204 V 0...367.2 V
Accuracy
(1
(at 23 ± 5 °C / 73±9 °F)
< 0.1% U
Max
< 0.1% U
Max
< 0.1% U
Max
< 0.1% U
Max
< 0.1% U
Max
Line regulation at ±10% ΔU
AC
< 0.02% U
Max
< 0.02% U
Max
< 0.02% U
Max
< 0.02% U
Max
< 0.02% U
Max
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy
(3
≤ 0.2% U
Max
≤ 0.2% U
Max
≤ 0.2% U
Max
≤ 0.2% U
Max
≤ 0.2% U
Max
Remote sensing compensation Max. 5% U
Max
Max. 5% U
Max
Max. 5% U
Max
Max. 5% U
Max
Max. 5% U
Max
Voltage regulation (power supply)
Load regulation at 0...100% ΔI
OUT
< 0.05% U
Max
< 0.05% U
Max
< 0.05% U
Max
< 0.05% U
Max
< 0.05% U
Max
Rise time 10...90% ΔU
OUT
Max. 30 ms Max. 30 ms Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔI
OUT
< 1.5 ms < 1.5 ms < 1.5 ms < 1.5 ms < 1.5 ms
Ripple
(2
< 800 mV
PP
< 200 mV
RMS
< 320 mV
PP
< 25 mV
RMS
< 320 mV
PP
< 25 mV
RMS
< 300 mV
PP
< 40 mV
RMS
< 320 mV
PP
< 55 mV
RMS
Fall time at no load after switching
DC output o󰀨
Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% U
Max
< 0.05% U
Max
< 0.05% U
Max
< 0.05% U
Max
< 0.05% U
Max
Current regulation (general)
Adjustment range 0...20.4 A 0...244.8 A 0...244.8 A 0...142.8 A 0...81.6 A
Accuracy
(1
(at 23 ± 5 °C / 73±9 °F)
< 0.2% I
Max
< 0.2% I
Max
< 0.2% I
Max
< 0.2% I
Max
< 0.2% I
Max
Line regulation at ±10% ΔU
AC
< 0.05% I
Max
< 0.05% I
Max
< 0.05% I
Max
< 0.05% I
Max
< 0.05% I
Max
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy
(3
≤ 0.2% I
Max
≤ 0.2% I
Max
≤ 0.2% I
Max
≤ 0.2% I
Max
≤ 0.2% I
Max
Current regulation (power supply)
Load regulation at 0...100% ΔU
OUT
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
Current regulation (el. load)
Load regulation at 0...100% ΔU
IN
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
< 0.15% I
Max
Ripple
(2
< 16 mA
RMS
< 160 mA
RMS
< 160 mA
RMS
< 44 mA
RMS
< 35 mA
RMS
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to di󰀨er max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal
