Elentek EXPRESS PRO - Page 21

21
FILLING OR EMPTYING LEVEL PROBES
This parameter enables selection of whether the C-MIN-MAX probe input
is used in emptying or filling mode.
In FILLING mode, the input is used to enable the system when water is not
present. The C-MIN-MAX input must be open to enable the system. If a
float-type on/off control is used, use C and MAX input.
In EMPTYING mode, the input is used to enable the system when water is
present. The C-MIN-MAX input must be closed to enable the system. If a
float-type on/off control is used, use C and MAX input.
NB: If no minimum level control is used, jumper C and MAX input.
FILLING
EMPTYING
PROBE SENSITIVITY
This parameter allows the probe sensitivity level to be adjusted.
1 - 9
FLOAT START/STOP FUNCTION ENABLE (self-holding)
This parameter allows active pumps to be deactivated only on opening of
the contact C and MAX (min./stop float).
This function is only available with pump rotation enabled and is only used
for emptying systems.
Y / N
MINIMUM LEVEL ALARM ACTIVATION
This parameter allows the cumulative alarm output to be removed for
minimum level.
Y / N
EXPANSION TYPE
This parameter allows any added expansion to be removed.
0 = no expansion applied
1 = PRO6DO expansion (6 digital outputs)
2 = PROSL expansion (lever probes for motor start)
3 = PROSL expansion (water seepage probes into oil chamber)
4 = PROSL expansion (water seepage probes into oil chamber and stop
motor)
0 - 4
MODBUS ADDRESSES
10
