Product description
EN
3.3 Technical specications
All information in this section relates to an ambient temperature of 20°C.
3.3.1 Summary of the technical parameters
Technical specications
Compakt
Rated voltage 400 V 3 AC, 50 Hz or 24 V DC
Control power supply 24 V DC
Force, dynamic up to 15,000 N
Force, static up to 15,000 N
Stroke speed approx. 1.5 mm/s to 65 mm/s
Stroke length up to 1000 mm
Rated current up to 1.3 A with AC
1)
up to 10 A with DC
1)
Power up to 900 VA with AC up to 240 W with DC
Duty cycle See data plate
Length of the control and
connection cables
1.50 m
2)
Protection class IP 54
Operating temperature
range
- 10°C to + 50 C
Airborne noise emission > 70 dB (A)
3)
Weight up to 20 kg
Tab. 1 Technical parameters
1)
If voltage surge protection devices are used, the exact current draw of the unit must be calcu-
lated prior to installation.
2)
Depending on customer requirement, between 1.5 m and 10.0 m on AC version and between
1.5 m and 5 m on DC version possible.
3)
1 m distance; 1.6 m above unit; nominal operation; measuring tolerance 10 %
You can refer to the type plate for the variant-dependent values of your device.
