Installation
Teach-in of the limit position “Retracted” (green button):
5. Traverse the drive to the desired position.
6. Savethepositionbybrieypressingthegreenbutton.
9 The green button lights up.
The limit position “Retracted” is taught in.
7. The green button goes out when the piston is moved away from the limit
position.
Precision adjustment of the limit positions:
A precision adjustment of the limit positions is not possible until both limit posi-
tions have been taught in. The precision adjustment can be performed or correc-
ted several times. The drive must be located in the relevant limit position.
1. Traverse the device to the corresponding limit position until the red or green
button lights up.
2. To adjust the exact position of the limit position press the corresponding
button once or several times.
Red button: increases the traversing range
Green button: decreases the traversing range
Each press of the button represents approximately 0.3 mm.
Press the button a maximum of eight times. The position then has to be reap-
proached.
3. Approach the position again to check the precision adjustment.
4.4.2 Displays in the event of errors
Theerrorsituationsdescribedbelowaresignalledbytheashingoftheredand
greenbuttons.Ifthedisplayisashing,thedevicecannolongertraversefor
safety reasons.
Green button ashing fast (> 3 Hz):
• The drive has overrun a limit position and has stopped on the safety limit
switch.
• Under normal operating conditions the drive cannot be traversed again to
an operational position.
• To do so, please contact our technical customer service department (see
section 1.6 “Customer service of the manufacturer”).
