elero Compakt - Electrical Connection

17
Installation
EN
4.2 Electrical connection
WARNING
Danger of life-threatening injury due to faulty electrical connection.
Electric shock possible.
•
Check the proper connection of the PE conductor prior to initial start of ope-
ration.
CAUTION
Damage to the device due to faulty electrical connection.
•
Take note that the motor and control unit have different supply voltages.
CAUTION
Damage to the device due to mishandling.
•
Operation must not take place without integration into and evaluation of the
limit switches in the control unit.
CAUTION
Damage to unit for versions with 400 V 3 AC caused by faulty electrical connec-
tion.
•
Alwaysconnectthemonitorcabletoaright-handrotaryeld.
CAUTION
Damage to the device due to the use of a non-fitting or unsuitable drive control
unit.
•
The control unit must support all the options attached to the device.
Nocircuitdiagramsarelistedbelowonaccountofthemultitudeofconguration
possibilities.
The device has to be connected in accordance with the circuit diagram enclosed
with the delivery.
Please refer to the following pages or the circuit diagram enclosed with the
delivery for connection of the option selected by you.
