elero Compakt - Operation of Unit; Dimensions Sheet

23
Installation
EN
The green and red buttons are ashing alternately:
• An internal error has occurred in the electronic path acquisition.
• Toresettheerror,brieyswitchoffthecontrolvoltage.
• When the control voltage is reconnected the error will be reset.
• Ifthealternateashingoccursagain,contactourtechnicalcustomerservice
on this subject (see section 1.6 “Customer service of the manufacturer”).
4.4.3 Operation of unit
CAUTION
Damage to the device due to wrong operation.
• The thermal protection switch must not be used as a regular overload swit-
ching device.
• Fast polarity reversal of the traversing direction of the drive is not permissi-
ble.
• The drive must come to a complete standstill before changing the direction of
movement.
4.5 Dimensions sheet
Onaccountofthemultitudeofcongurationpossibilitiesnodimensionssheets
are listed below.
You can request from the manufacturer an exact dimensions sheet for the de-
vice supplied, if required.
