16
Installation
CAUTION
Damage to the device due to the connecting rod jamming.
• The linear path of the piston must be freely moveable at all times.
• The pivoting range of the device must be kept free.
CAUTION
Damage to the device due to loss of the support and holding function.
• Pay attention to static loads.
The device was manufactured with the circuit diagram ordered by you. The
designation can be found in the sales documentation or the circuit diagram enc-
losed with the delivery.
In delivery condition (factory setting), the connecting rod is already slightly
extended. Please refer to the sales documents for the minimum and maximum
dimensions.
4.1 Mechanical fastening
CAUTION
Damage to the device due to radial and/or torsional forces.
• No radial and/or torsional forces must be allowed to act on the device.
CAUTION
Damage to the electrical leads due to crushing or a tensile load.
•
All electrical leads have to be laid so that they are not exposed to any crus-
hing or tensile loads.
Fasten the device only by the fastening elements provided for this purpose.
These are located on the housing side and on the connecting rod (see Fig. 1
"Components of a device").
