MODULAR STACKING BENCH MOUNTED RESERVOIR ON TOP (OPTIONAL)
1a
Remove carefully
a. Open doors and undo quarter turn
fasteners.
b. Remove front panel and undo lid bolt
with an allen key. (6mm AF FXBOYR301716)
c. Remove bolt and lift the lid.
d. Place the reservoir on top, lining up
with the three points. Screw in allen
head bolt, before replacing front panel.
ONLY PLACE ONE CHORUS SYSTEM ON TOP OR BELOW THE RESERVOIR.
WARNING!
SET - UP
