24
10. Rear of the unit
ST9
INPUTS ST3
ST4
ST7
Power
Supply
RS-232
ST2
Encoder
Y
Fuse
0,4 A
1
2
3
OUTPUTS ST5 ST6
ST1
Encoder X
