4.4 Manual inching
Press
T Æ to reset all target windows to zero
Use
Hand/Single Æ to activate Hand mode Æ the appropriate LED shines
The buttons
7/8/9/NR can be used to move the axis forward and backwards at high and
low speeds (whilst the button is depressed).
Press
> Æ to select the axis, which want to be moved
Press
7 Æ to move slow reverse
Press
8 Æ to move fast reverse
Press
9 Æ to move fast forwards
Press
NR Æ to move slow forwards
If a 3 speed drive is used, the
fast and creep speeds are used. The physical direction
of movement, can be reversed by setting of Register
R64. When operating in switched
speed mode (i.e. without analog output) the outputs
fast/slow/creep/reverse are set
according to the button pressed.
When closed loop analog control is used, the respective speeds are set in R60… R63
in rpm. The proportional analog output voltage is given, when the button is pressed.
5. Register Input
5.1 Unlocking Registers by Security Code
The values of Registers R1… R97 can be changed after the security code 250565
has been entered into Register R98 (Exception R6/R7/R40).
The security code can be entered in program mode.
Use the button
E to Æ a) save register values b) end editing
Press
Prog Æ Controller is set to program mode. Prog - LED shines.
Press
R Æ The Nr. window flashes
Press
C Æ Clears display to zero
Type in
98 Æ Value 98 appears in Nr. window flashes “8”
Press
> Æ The Target window shows “000000” without decimal point
Press
C Æ Clears display to zero
Type in
250565 Æ Display shows 250565 (the security code)
Press
E Æ The Controller is now set to data entry mode.
All Windows are set to zero. Decimal point is reinstated.
