12. Technical specifications
Function Data
Power supply
+24 VDC
(e.g. with ext. power pack NG 13.0) or
230V/115V AC +/- 10 %
Note: Please don’t exceed the max. load of 600 mA (max. available with NG 13.0,)
when connecting the equipment, inclusive connected encoders and loaded resp.
activated output signals.
Consumption
max. 110 mA at + 24 V DC with unloaded outputs
or 50 / 100 mA at 230 / 115 V AC 50 / 100 mA
Encoder supply 24 V DC; max. 130 mA
Input signals
PNP (standard): Active high (+24 VDC)
NPN (option): Active low (GND)
Input pulse time min. 300 ms
Input current / Pin max. 10 mA
Output signals are - push/pull
- caused short circuit proof
- with a max. load of 50 mA
- with integrated recovery diode
Power down memory E
2
Prom, service life: 10
5
power- on/off cycles
Connectors D-SUB
Displays Red LED displays, height: 10 mm
Hardware 16-Bit Micro controller with 256 Kbytes E-Prom and 32 Kbytes RAM
System accuracy +/- 1 Digit
Input frequency
20 KHz (more on request) corresponding to 0.1 mm resolution
resp. an operating speed of 120 m / min
Panel cut out B x H = 138 x 138 mm’s
Install depth 75 mm’s without connectors
110 mm’s including connectors
Ambient temperature 0°… + 45°
NG 13.0 - External POWERPACK
Input voltage 230 V / 115 V AC +/- 10 %
Input frequency 50 - 60 Hz
Power consumption 40 VA
Output voltages 10 VDC / 24 VDC
Output current 400 mA / 600 mA
Connections Screw terminal for a wire cross section of max. 2 x 2,5 mm
2
