Electromagnetic flowmeter FLONET FH30xx
ELIS PLZE a. s., 425/15, , Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K
7.3.1.2 Main menu
Language
Displayed data
Current output
Output functions
Serial line
Date setting
Time setting
Volume resetting
Number of samples
Suppressed flow rate
Zero setting
Manufacturing data
Factory setting
Simulated flow
The selected item will be shown in a highlighted window where it can be opened by actuating the ENTER
control button. When scrolling up or down in the menu, always four neighbouring items will be shown.
The manufacturer supplies the flowmeter verified as to its functions, calibrated and with
             
observance of the requirements specified in the product manual, the flowmeter will be ready for
immediate operational start.
In cases where the user requires an accelerated procedure for the meter commissioning and
setting of the meter parameters with respect to the given operational conditions and the co-
operating higher-level control system, it suffices to set the parameters shown in bold print in the
above list of the main menu items.
Detailed description of the meter control procedures is given in the manual:
Es 90686K Electromagnetic flowmeters of the type series FLONEX FXx11x and FLONET
FH30xx Meter control instructions
To move upward in the menu,
use button 
Fast meter operational start
To move downward in the menu, use
button 
