ELIS PLZE a. s., 425/15, , Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K
7.3.2 Remote meter control using the FLOSET 4.0 program
Flowmeters of the type series FLONET FH30xx are provided with the digital interface RS-485 MODBUS
RTU and interface HART
.
Through an interface RS-485 and communication software FLOSET 4.0 the meter can be connected
as subordinated equipment to a computer (a personal, notebook or tablet computer) with Windows 7 or
higher OS upgrade (Linux, iOS) with JAVA 8u40 or higher.
FLOSET 4.0 is not included in the scope of delivery.
On request we can deliver:
software
software User Guide
-485 converter with connection cables
Program FLOSET 4.0 makes it possible to:
• read the measured quantities (volume flow rate and flow volumes passed through the meter sensor
in both directions);
• set the parameters of the measured quantities to be displayed (units and number of decimal
positions);
• set the multifunction output parameters (in the binary, pulse or frequency operational modes), and
the current output parameters;
• set the flowmeter language, date and time;
• set the digital interface parameters;
• set the data archiving parameters and read the archived data;
• monitor extraordinary operational events and read the archived data on such occurrences.
7.3.2.1 Communication interface MODBUS RTU
The physical form of this interface consists of a serial line RS-485 of the following parameters:
• Speed 300, 600,1200, 2400, 4800, 9600, 19200, 38400, 57600 Bd;
• 8 data bits, 1 stop bit;
• No parity.
Detailed description of communication via interface RS485 MODBUS RTU is given in the manual:
Es 90664K Communication interface RS-485 MODBUS RTU
Electromagnetic flowmeters FLONET FH30xx and FLONEX FXx11x
