2 METER IDENTIFICATION
2.1 FLONET FH30xx flowmeter type designation
Review of the flowmeter FLONET FH30xx design versions:
FLONET FH30xx
4  Compact version COMFORT
5  Remote version COMFORT
0  Non-standard sensor design
1  Flanged flow-rate sensor
2  Wafer flow-rate sensor
0  Normal operating environment
3  Transmitter C14.00 (95 to 250VAC) / C15.00 (24V  20%)
2.2 Scope of delivery
2.2.1 Compact meter version FLONET FH30x4
• Flowmeter FLONET FH30x4 with interfaces RS-485 MODBUS RTU
• Product manual  Electromagnetic flowmeter FLONET FH30xx
• Product manual  Electromagnetic flowmeters of the type series FLONEX FXx11x and FLONET
FH30xx Meter control instructions
• Product manual  Communication interface RS-485 MODBUS RTU
Electromagnetic flowmeters FLONET FH30xx and FLONEX FXx11x
2.2.2 Remote meter version FLONET FH30x5
• Transmitter for FLONET FH30x5 including signal cable / connector, communication interface
RS-485 MODBUS RTU and communication interface HART
• Meter sensor and connection box
• Product manual  Electromagnetic flowmeter FLONET FH30xx
• Product manual  Electromagnetic flowmeters of the type series FLONEX FXx11x and FLONET
FH30xx Meter control instructions
• Product manual  Communication interface RS-485 MODBUS RTU
Electromagnetic flowmeters FLONET FH30xx and FLONEX FXx11x
• Transmitter holder
