ELIS PLZE a. s., 425/15, , Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K
The initial output parameter setting is described in the flowmeter delivery note.
2.4.3 Sensor plate
The sensor rating plate is attached to the induction sensor housing.
Both compact and remote meter versions
Example of the sensor plate
Comments
1 Sensor pressure parameters in reference to the PED directive
2 Ambient temperature
3 Temperature of the measured fluid
3 METER DESIGN AND MATERIAL VERSIONS
3.1 Compact and remote meter versions
In the cases of compact flowmeter version, the meter sensor and transmitter are connected internally
and are integrated into a single unit.
In the remote meter version, the sensor and transmitter are connected by a cable.
The remote flowmeter version is preferable in the following cases:
• the measured fluid temperatures in excess of 70C;
• space limitations not permitting application of the compact meter version;
