Elite Screens Ez-Frame Series - Attach Corner Joint Connectors

www.elitescreens.com / eliteinfo@elitescreens.com
Please do not tighten the screws completely, to make sure the frame piece lines up
correctly.
3. Insert both corner joint connectors into the long (horizontal) frame (see fig.1)
4. Join all four frame parts together following the steps showed below. (fig.2)
Long frame
Push
Push
Joint
( fig.1)
Push
Push
Short frame
Short frame
