(4) Place a fix plate in the center of each side in the following orderE→F→G→H.(Fig.9)
(5) Next, fasten a fix plate on the center of each frame side in the following order I
$
J
$
K
$
L
$
M
$
N
$
O
$
P as shown in Fig.10.
(6) Fasten the remainder of the fix plates in the empty locations in the red markings to complete
attaching the screen material. (Fig.11)
Tip for attaching the last corner (D):
1. Position yourself left of location
%
.
2. Pull the material to the corner of the frame with your hand while your left
hand snaps in the fix plate on location
%
(the third red dot).
3. Then insert and snap in the fix plate on location
&
.
4. Next, moveand position yourself on location
'(
then pull the edge to
the frame and fasten plates on locations
'
and
)
.
*
+
,
-
.
Pull
(Fig. 8)
E
G
H
F
(Fig.9)
(Fig.10)
I
J
K
L
M
N
O
P
