Attaching the screen material to the frame
1. Unroll the screen material facing down on a clean area or on the protection sheet (k) if included.
2. Insert the tension rods (e) separately into the edges of all four corners of the material.
Tension rods (e)
3. Distribute and place the pre-installed springs in the frame on each hole of the material.
4. Use the spring hook (d) to attach the screen material. Begin by securing the four corners with the springs to the
frame in A-B-C-D order as illustrated below.
Note: Hold the tension rod in the screen material with left hand, hook the spring with right hand, and
finally use the spring hook onto the tension rod in the screen material hole, as shown as below.
A
C
Spring hook (d)
Springs
Screen material (l)
D
B
tension rod (e)
5. Next, attach a spring in each center point locations (1), then out of the center location (2), and finalize the
installation with the remaining springs.
2
2
1 1
2
2
2
1
2
