FITTING THE BICYCLE
• Lower the resistance unit completely (Ref. B),
unscrewing the bolt regulator of the resistance
unit plate (Ref. V) (Fig. 9).
• Make sure the quick release of the bicycle rear
wheel is properly fixed.
• Turn the lever (HH) to the “open” position (fig.
10).
• Release the ring (EE) by unscrewing it (fig. 11).
• Put the bicycle in position, inserting the left end
of the rear quick release in the left bushing
(fig.12).
• For safer clamping of the bicycle on the stand,
make sure the lever of the quick release is
horizontal (fig.13).
• Close the lever (HH), making sure it starts
pressing the quick release inside the predefined
work area; between 30° and 45° (fig. 14 and
fig.15).
