Eliwell EWCM 4120 - Parameter CF04-CF11 Limits Table

68
1
* Display in decimals if M.U. °C/°F/Psi, in centimetres if Bar.
2
* Display in decimals if M.U. °C/°F/Bar, in units if Psi.
For determination of the UM and decimal point, see also parameters CP and Fn.
Parameters CF04 ..CF11 limits table
These limits depend on the measuring unit (parameters UI22 and UI23):
°C °F Bar Psi
Par.
Min Max Min Max Min Max Min Max Min Max Min Max
Hi Lo Hi Lo
CF04 - - - - CF05 40.00 - - CF05 580.0 - -
CF05 - - - - -5.00 CF04 - - -72.5 CF04 - -
CF06 - - - - - - CF07 100.0 - - CF07 1450
CF07 - - - - - - -5.0 CF06 - - -72 CF06
CF08 -10.0 10.0 -18.0 18.0 - - - - - - - -
CF09 -10.0 10.0 -18.0 18.0 - - - - - - - -
CF10 -10.0 10.0 -18.0 18.0 -1.00 1.00 - - -14.5 14.5 - -
CF11 -10.0 10.0 -18.0 18.0 - - -10.0 10.0 - - -145 145
Hi: High resolution; Lo: Low resolution;
WARNING The number of decimal points will therefore depend on the type of measuring unit and its resolution.
