Eliwell EWCM 4120 - Page 67

67
AL02 Inlet pressure switch alarm bypass time 0…255 0 0 0 secs
AL03 Number of outlet pressure switch events 0…33 0 0 0 num
AL04 Outlet pressure switch alarm bypass time 0…255 0 0 0 secs
AL05 Number of inlet low analogue alarm events 0…33 0 0 0 num
AL06 Inlet low analogue alarm bypass time 0…255 0 0 0 secs
AL07 Number of inlet high analogue alarm events 0…33 0 0 0 num
AL08 Inlet high analogue alarm bypass time 0…255 0 0 0 secs
AL09 Number of outlet low analogue alarm events 0…33 0 0 0 num
AL10 Outlet low analogue alarm bypass time 0…255 0 0 0 secs
AL11 Number of outlet high analogue alarm events 0…33 0 0 0 num
AL12 Outlet high analogue alarm bypass time 0…255 0 0 0 secs
AL13 Number of compressor shut-down alarm events 0…33 0 0 0 num
AL14 Compressor shut-down alarms bypass time 0…255 0 0 0 secs
AL15 Number of fan thermal switch alarm events 0…33 0 - 0 num
AL16 Fan thermal switch alarms bypass time 0…255 0 - 0 secs
AL17 Inlet probe maximum alarm switch-on threshold -999…9999 350 350 350 CFBP
1
AL18 Hysteresis for switching off inlet probe maximum alarm 0…9999 50 50 50 CFBP
1
AL19 Inlet probe minimum alarm switch-on threshold -999…9999 160 160 160 CFBP
1
AL20 Hysteresis for switching off inlet probe minimum alarm 0…9999 50 50 50 CFBP
1
AL21 Outlet probe maximum alarm switch-on threshold -999…9999 195 195 195 CFBP
2
AL22 Hysteresis for switching off outlet probe maximum alarm 0…9999 20 20 20 CFBP
2
AL23 Outlet probe minimum alarm switch-on threshold -999…9999 134 134 134 CFBP
2
AL24 Hysteresis for switching off outlet probe minimum alarm 0…9999 20 20 20 CFBP
2
AL25 Maximum number of events in alarm log for alarm signal 0…99 0 0 0 num
