LINK PARAMETERS - Label Lin - EWDR 985/CSK (LX) ONLY - SEE PAGE 12
folder nAd For each day of the week d0…d6/Ed parameters Evento E00…E03 can be displayed/programmed (see also nad table).
PAR. DESCRIPTION
RANGE DEFAULT VALUE* LEVEL** U.M.
OAO High and low temperature alarm delay after dis-
abling digital input (door closed)
0...10 0 2 hours
Alarms-AL label
tdO Time out after alarm signal when digital input is
disabled (door open)
0...250 0 2 min
tAO (5) Temperature alarm delay time
0...250 0 1-2 min
dAt Alarm for defrosting ended due to time out.
n=alarm not active y=alarm active
n/y n 2 flag
EAL External alarm to lock controllers n=does not lock,
y=locks
n/y n 2 flag
AOP Polarity of alarm output: 0 = alarm active and out-
put disabled; 1 = alarm active and output enabled
0/1 1 2 flag
PbA Configuration of temperature alarm on probe 1
and/or 3:
0=on probe 1 (thermostat control)
1=on probe 3 (display)
2=on probe 1 and 3 (thermostat control and display)
3=on probe 1 and 3 (thermostat control and display) on external threshold
0/1/2/3 0 2 num
SA3 Probe 3 alarm set point
-50.0...150.0 50 2 °C/°F
dA3 Probe 3 alarm differential
-30.0...30.0 2.0 2 °C/°F
dEA DEA= device number within the family
(valid values: from 0 to 14)
FAA FAA= device family (valid values: from 0 to 14)
The value couple FAA and dEA represents the network address of the device and it is indicated in the following way: "FF.DD" (where FF=FAA and DD=dEA).
0...14 0 1-2 num
Night & Day Control-
nAd label
E00 Functions enabled during events;
0=control disabled 1=reduced set point
2=reduced set point+light
3=reduced set point+light+aux / 4=instrument off
0...4 0 1-2 num
E01 Hours/minutes of start of intervention. Starting
from this time, the “NIGHT” mode will be enabled.
The duration is determined by EO2
0...23/0...59 0 1-2 hours/min
E02 Duration of event. Sets the duration of the event
that begins at time E01 determined by value E00
0...99 0 1-2 hours
E03 (6) Blocking/unblocking daily or holidays defrosting.
0= “work days” defrost sequence defined by
parameters dE1...dE8;
1= “festive/holidays” defrost sequence defined
by parameters F1...F8
0/1 0 1-2 flag
EWDR 983-985/CS (LX) - EWDR 985/CSK (LX) 6/12
Light & digital inputs
Lit Label
*EWDR 985/CSK (LX)
ONLY
dSd Light relay enable from door switch.
n = door open, light does not turn on;
y = door open, light turns on (if it was off)
n/y y 2 flag
dLt Light relay disabling delay after closing door if
“dSd”=y
0...31 0 2 min
OFL Light relay disabled even if disabling delay
“dLt” is active
n/y n 2 flag
dAd Delay in enabling digital input
0...255 0 2 min
dOd Digital input switches off loads
n/y n 2 flag
dOA* Forced behaviour from digital input:
0=no enabling; 1=compressor enabled
2=fans enabled;
3=compressor and fans enabled
0/1/2/3 0 2 num
PEA* Enables forced behaviour from door light and/or
from external alarm
0=function disabled; 1=associated with door light
2=associated with external alarm;
3=associated with door light and external alarm
0/1/2/3 0 2 num
dCO* Delay in enabling compressor with consensus
0...250 0 2 min
dFO* Delay in enabling fans with consensus
0...250 0 2 min
Communication
Add label
