DANGER
LOOSE WIRING CAUSES ELECTRIC SHOCK
Tighten connections in conformance with the torque specifications.
Failure to follow these instructions will result in death or serious injury.
The table below displays the type and the size of cables for disconnectable terminals with pitch 5.00 mm (0.197 in.) or 5.08 mm (0.2 in.).
Ø 3.5 mm (0.14 in.)
mm
2
AWG
0.2…2.5
24…13
0.2…2.5
24…13
0.25…2.5
22...13
2 x 0.25…1
2 x 22…18
2 x 0.2…1.5
2 x 24…16
2 x 0.2…1
2 x 24…18
2 x 0.5...1.5
2 x 20...16
mm
in.
7
0.28
C
0.5...0.6
4.42...5.31
N•m
lb-in
0.25…2.5
22...13
DANGER
POTENTIAL OF OVERHEATING AND FIRE
• Do not use with loads other than those indicated in the technical specification.
• Do not exceed the maximum permitted current; for higher loads, use a contactor with sufficient power capacity.
Failure to follow these instructions will result in death or serious injury.
This device has been designed to operate outside of any dangerous location.
Only install this device in zones known to be free of hazardous atmosphere.
DANGER
POTENTIAL FOR EXPLOSION
Install and use this equipment in non-hazardous locations only.
Failure to follow these instructions will result in death or serious injury.
