Eliwell ICPlus 915 - Page 24

PAR. DESCRIPTION MODEL RANGE VALUE M.U. LEVEL
H02
Press the ESC, UP and DOWN keys (if configured for a second function) for the
time H02 to activate the function itself.
N.B.: The AUX function has a fixed activation time of 1 second.
ALL 0...15 5 secs Inst
H03
Lower input current/voltage limit.
(only present on model V/I)
NTC/PTC
User/InstPT100-Tc
V/I -1999...1999 0 num
H04
Upper current/voltage limit for input.
(only present on model V/I)
NTC/PTC
User/InstPT100-Tc
V/I -1999...1999 1000 num
H05
Window filter:
-2 = very fast; -1 = fast; 0 = normal; 1 = slow; 2 = very slow.
ALL -2/-1/0/1/2 0 num Inst
H06
Key or Digital Input with aux/light or door switch active with the device OFF (but
powered). n (0) = not active; y (1) = active.
ALL n/y y flag Inst
H08
Stand-by operating mode.
0 = only display switches off; 1 = display on and controllers locked;
2 = display off and controllers locked.
ALL 0/1/2 2 num Inst
H10
Delay for output activation after Power On. If H10 = 0 the delay is NOT active; if
H10 ≠ 0 the output will not be activated before this time has expired.
ALL 0...250 0 min Inst
H11
Digital Input Configuration.
0 = disabled; 1 = SOFT START; 2 = Offset setpoint; 3 = Outputs stopped;
4 = Periodic cycle; 5 = AUX; 6 = Stand-by; 7 = Not used;
8 = External alarm; 9 = External alarm to lock regulators.
NTC/PTC 0..9 0 num
InstPT100-Tc 0...9 0 num
V/I
H13
Polarity and priority of Digital Inputs (D.I.).
no (0) = normally open; nc (1) = normally closed;
noP (2) = normally open with priority; ncP (3) = normally closed with priority.
NTC/PTC no/nc/noP/ncP no num
Inst
PT100-Tc no/nc/noP/ncP no num
V/I
H14 Digital input activation delay.
NTC/PTC 0...250 0 min
InstPT100-Tc 0...250 0 min
V/I
