ES 50 – ES 80
15
Typical Data ES 50 ES 50S ES 60 ES 60HS ES 80
Drawn power [kW] 0.26 0.37 0.26 0.37 0.26
Opening and closing time
[s]
approx. 4.0 approx. 4.0 approx. 5.5 approx. 4.0 approx. 8.5
Max. boom length [mm] 5,000 5,000 6,000 6,000 8,000
Effective length [mm] 5,140 5,140 6,140 6,140 8,140
Fixed support / swinging
support
required required required required required
Reversing on obstacle selectable selectable selectable selectable selectable
Boom weight [kg] 10 10 16.5 16.5 23
Boom weight (round boom,
optional) [kg]
9 9 11 11 18.5
Barrier weight [kg] approx. 116 approx. 116 approx. 124 approx. 124 approx. 138
Table 3
The barriers ES 50 to ES 80 are for vehicle-traffic only!
6.1 Operation - Safety – Wind load class
WARNING!
Risk through high wind loads!
The barrier use during high wind loads can lead to barrier boom damage and/or damage to the boom
connector.
 The barrier use during higher wind loads as shown in the table below is prohibited.
 The figures below refers to the closed barrier and not to the ability to open and close the barrier
during high wind loads.
 During high wind loads the barrier boom must be secured or dismantled!
Type
Barrier
boom
Swinging
support /
Fixed
support
Folding skirt
or
top and bottom
skirt
max. permitted
wind load
class
Windspeed
(km/h)
ES 50
Standard
boom
Swinging
support
without 4 up to max. 133
HG 75 2 up to max. 90
Fixed
support
without 4 up to max. 133
HG 75 3 up to max. 117
Round
boom
Swinging
support
without 4 up to max. 133
Fixed
support
without 4 up to max. 133
ES 50 S
Standard
boom
Swinging
support
without 4 up to max. 133
HG 75 2 up to max. 90
Fixed
support
without 4 up to max. 133
HG 75 3 up to max. 117
Round
boom
Swinging
support
without 4 up to max. 133
Fixed
support
without 4 up to max. 133
ES 60
Standard
boom
Swinging
support
without 4 up to max. 133
HG 75 3 up to max. 117
HG 150 (max. 4.5m) 4 up to max. 133
SG 150 (max. 4.5m) 4 up to max. 133
Fixed
without 4 up to max. 133
