Pos. Qty. Part name
1 1 Drive lever
2 1 Gearbox shaft
3 1 Main shaft
4 1 Main plate
5 / 6 1 Gearbox support left / right
7 1 Thrust piece
8 1 Lift rod
9 1 Connecting lever
10 1 Bowden cable support
11 1 Emergency release bolt
12 2 Pillow block
13 1 Emergency release lever
14 / 15 2 / 1 Distance plate 1mm / 2mm
16 / 17 / 18 1 Motor ES 60 / ES 50+80 / ES 50S
19 / 20 1 Gearbox ES 50 / ES 50S /ES 60+80
21 1 Housing – bottom part
22 1 Access panel
23 1 Hood
24 1 Lock
25 / 26 1 Mounting plate - complete
27 1 Button OPEN-CLOSE
28 1 Limit switch holder
29 1 Micro-switch standard
30 1 Lead for stop contact
31 1 Limit switch wire set
32 1 Bowden cable
33 / 34 / 35 1 Spring assembly ES 50 / ES 60 / ES 80
36 1 Tension spring
37 1 Base plate support
38 1 Left and right boom holder supports
39 1 Covering plate
40 / 41 1 Boom connector ES 50 / ES 60+80
42 / 43 1 Boom reinforcement ES 50 / ES 60+80
44 / 45 / 46 1 Boom ES 50 / ES 60 / ES 80
47 1 Boom connecting piece
48 / 49 1 Boom end cap ES 50 / ES 60+80
Table 17
