- 6 -
TER-9
15 16 18 25 26 28
A1 A2 T1 T1 T2 T2
PRG +
MAN
_
MAN 2
ESC
OK
RESET
Auto
Zaciski napięcia zasilania (A1)(A2)
Wyświetlacz z podświetleniem
Miejsce na plombe
Przyciski sterowania
Wyjście - kanał 2 (25-26-28)
Wyjście - kanał 1 (15-16-18)
Opis aparatu
Zaciski -czujnik 1
Zaciski -czujnik 2
Wkładka dla wymiany baterii
