- 6 -
TER-9
15 16 18 25 26 28
A1 A2 T1 T1 T2 T2
PRG +
MAN
_
MAN 2
ESC
OK
RESET
Auto
Svorka napájacieho napätia (A1)(A2)
Podsvietený displej
Plombovacie miesto
Ovládacie tlačidlá
Výstup - kanál 2 (25-26-28)
Výstup - kanál 1 (15-16-18)
Popis prístroja
Svorky -senzor 1
Svorky -senzor 2
Zásuvný modul pre výmenu záložnej batérie
