Elko TER-9 Manual

- 14 -
Prog
Prog Prog
Prog
Prog
+
_
+
_
ESC
ESC
OK
OK
T1
Ts1
dy1 dy2
dy1
dy2
15-18
H1
H1
25-28
T2
Ts2
dy1
dy2
dy1
dy2
H2
H2
selection of unit
Legend:
Ts1 - real (measured) temperature 1
Ts2 - real (measured) temperature 2
T1 - adjusted temperature T1
T2 - adjusted temperature T2
H1 - adjusted hysteresis for T1
H2 - adjusted hysteresis for T2
dy1 - set switching delay of the output
dy2 - set delay on output breaking
15-18 output contact (for T1)
25-28 output contact (for T2)
- Output contact switched until adjusted
temperature is reached. Hysteresis elimi-
nates frequent switching. Heating/cooling
function adjusted in the menu.
setting temperature
units
set
set
units units
end
2 independent single-stage thermostat
Heater function
Heater function
Thermostat functions
- long press (>1s)
- short press (<1s)
